“Old School ranging solutions - for the long range rifleman...”


In today’s modern world of electronic “gizmos”, there are many excellent ranging devices and equipment on the market today… usually requiring a battery.

The MIL-DOT RANGE GUIDE offers the long range shooter an alternate method of ranging by incorporating a “getting back to basics…” approach to enhance the shooter’s skill set and providing proficient and repeatable accuracy “down range” where it counts.

By using the fundamentals of MOA and MIL-DOT ranging methodology and techniques and operating on the proven mathematical principles of geometric angular measurements - ranging solutions and windage corrections are made available on 3 double sided polystyrene-all weather panels in both MOA and MIL-DOT measurements - resolving ranging resolutions quickly and accurately.

“When your battery operated range finder fails... use your head!”

GETTING BACK TO BASICS...



RANGE GUIDE - MIL DOT WHIZ WHEEL FEATURES...

SIDE A - WHIZ WHEEL SIDE



  •  CALCULATE RANGE TO TARGET IN MIL-DOT
  •  CALCULATE COME UP CORRECTION FOR BULLET DROP IN MIL-DOT



SIDE B - WEATHER AND ATMOSHPHERIC CORRECTIONS SIDE

TABLE 1 - WEATHER & ATOMOSPHERIC EFFECTS

  • CORRECT FOR DENSITY ALTITUDE CHANGE

  • CORRECT FOR TEMPERATURE CHANGE

  • CORRECT FOR HUMIDITY CHANGE


TABLE  2- WIND QUARTERING CORRECTION GRAPH

  • CORRECT FOR WIND ANGLE

  • CORRECT FOR WIND VELOCITY


TABLE  3- ADJUSTED COSINE INDICATIOR GRAPH

  • CORRECT FOR ANGLE SHOTS FROM 15 TO 60 DEGREES


TABLE  4 - FLAG METHOD FOR WIND VELCOCITY AND ANGLE

  • ESTIMATE WIND VELOCITY AND ANGLE USING RANGE FLAG



TABLE  5 - MIL-MOA CONVERSION EQUATIONS

  • CONVERT MIL to MOA EQUATION

  •     CONVERT MOA to MIL EQUATION






***  SEE "MIL-DOT RANGE GUIDE" TAB AT THE TOP OF THIS PAGE FOR FULL RANGE GUIDE DESCRIPTION AND FUNCTIONALITY ...

THIS PRODUCT  IS 100% AND VERY PROUDLY


KEEP AMERICA STRONG - ENGINEER - MANUFACTURE - BUY AMERICAN!

AMERICAN MADE - AMERICAN PROUD!
